Submersible Sewage Cutter Pump,Marine Sewage Pump,Centrifugal Pump,Dirty Water Pump
WQ series submersible sewage pump is mainly used for municipal works, industrial buildings, hotels, hospitals, civil air defence, mines, etc. Trades to drain off the sewage, waste water, rainwater and living water in cities containing solid grains and various long fabrics.
Characteristics:
Curve:
dimension drawing:
Features:
Conditions of use
1. Medium temperature should not be over 40degree, the density no larger than 1200kg/m, and the PH value within5-9.
2. During running, the pump must not be lower than the lowest liquid level.
3. The maximum diameter of the solid grain going through the pump has not be larger than 50% of the pump outlet.
The above pump performance for reference only, details please contact us!
Our Advantages
FAQ
1. What is your product range?
A: centrifugal pump. Centrifugal pump includes slurry pump, gravel pump, clean water pump, sewage pump, chemical pump, self-priming pump and diesel engine pump.
2. What's your MOQ, payment term and lead time?
A: MOQ for centrifugal pump is 1set, MOQ for conveyor belt is 100cbm.
Payment Term: T/T, L/C, Western Union, Paypal and Trade Assurance.
Lead time: in general 7 working days for slurry pump, 15working days for water pump.
3. What information should I let you know if I want to get a quotation:
A: Pump capacity, pump head, medium, medium temperature, pump material, quantity, if possible, please also provide the pump model you are using now, price will be calculated as per the pump model, if not, we will recommend relevant product for reference.
4. If I put a bigger motor on my pump, will it pump more?
A: No. The amount of water and the pressure (head) that a centrifugal pump process is related to the rotational speed, impeller diameter and size of the impeller vanes.
5. Do you impact the finished product?
A: Yes, each batch of production and finished product will be quality checked strickly before delivering, testing report or video can be sent to clients for reference.
6. How do you ship the finished product?
A: By sea, By air, By international express.
Inquiry of Pump
1. Head: _____meter
2. Capacity: _____m3/h
3. Liquid media: ______
4. PH: _____
5. Concentration: ____%
6. Temperature: _____degree
7. Specific density; ______kg/m3
WQ series submersible sewage pump is mainly used for municipal works, industrial buildings, hotels, hospitals, civil air defence, mines, etc. Trades to drain off the sewage, waste water, rainwater and living water in cities containing solid grains and various long fabrics.
Characteristics:
| 200WQ300-16-22 TYPE SEWAGE PUMP | |
| Model | 200WQ300-16-22 |
| Capacity | 300 m3/h |
| Head | 16 m |
| Power | 22 kw |
| Color | As Customer Required |
| Casing material | Cast iron |
| Wet ends material | Cast iron |
| Shaft material | 45# steel |
| Shaft seal | Mechanical seal |
dimension drawing:
Features:
| Materials | ||
| Description | Standard Material | Material Options |
| Shaft | 420 Stainless Steel | |
| Pump Casing | Cast Iron | SS316/ Duplex |
| Impeller | Cast Iron | SS316/ Duplex |
| Neck Ring | Cast Iron | SS316/ Duplex |
| Motor Water Jacket | Mild Steel | SS316 |
| Motor Mechanical Seal | SS304 | |
| Wet End Mechanical Seal | SS304 | |
| Motor Body | Cast Iron | SS316 |
| Oil Housing | Cast Iron | SS316 |
Conditions of use
1. Medium temperature should not be over 40degree, the density no larger than 1200kg/m, and the PH value within5-9.
2. During running, the pump must not be lower than the lowest liquid level.
3. The maximum diameter of the solid grain going through the pump has not be larger than 50% of the pump outlet.
Our Advantages
- Factory direct price
- Professional knowledge and attentive service
- Strict quality inspection and timely delivery
- Highly value every order, no matter how small it is.
- offer confidentiality agreement "business secret contract"
- Product warranty:lifetime, no matter how long to use,if there is air hole in the flow parts,please return it,will give you a new one to replace.
FAQ
1. What is your product range?
A: centrifugal pump. Centrifugal pump includes slurry pump, gravel pump, clean water pump, sewage pump, chemical pump, self-priming pump and diesel engine pump.
2. What's your MOQ, payment term and lead time?
A: MOQ for centrifugal pump is 1set, MOQ for conveyor belt is 100cbm.
Payment Term: T/T, L/C, Western Union, Paypal and Trade Assurance.
Lead time: in general 7 working days for slurry pump, 15working days for water pump.
3. What information should I let you know if I want to get a quotation:
A: Pump capacity, pump head, medium, medium temperature, pump material, quantity, if possible, please also provide the pump model you are using now, price will be calculated as per the pump model, if not, we will recommend relevant product for reference.
4. If I put a bigger motor on my pump, will it pump more?
A: No. The amount of water and the pressure (head) that a centrifugal pump process is related to the rotational speed, impeller diameter and size of the impeller vanes.
5. Do you impact the finished product?
A: Yes, each batch of production and finished product will be quality checked strickly before delivering, testing report or video can be sent to clients for reference.
6. How do you ship the finished product?
A: By sea, By air, By international express.
Inquiry of Pump
1. Head: _____meter
2. Capacity: _____m3/h
3. Liquid media: ______
4. PH: _____
5. Concentration: ____%
6. Temperature: _____degree
7. Specific density; ______kg/m3
