Qdx submersible electric pump with float switch (aluminum shell)

APPLICATIONQ(D)X series submersible pump consist of pump, seal and motor, and equipmented with protection apparatus,It is designed for clean water, widely used for drawing water from well, farm irrigation, garden, building construction,breeding industry, and daily life. Moreover, it has small volume and light weight, more easy t

Featured Products

Qdx Electric Submersible Pump with Float Switch (Aluminum Housing)
Qdx Electric Submersible Pump with Float Switch (Aluminum Housing)
Qdx Electric Submersible Pump with Float Switch (Aluminum Housing)


APPLICATION

Q(D)X series submersible pump consist of pump, seal and motor, and equipmented with protection apparatus,

It is designed for clean water, widely used for drawing water from well, farm irrigation, garden, building construction,

breeding industry, and daily life. Moreover, it has small volume and light weight, more easy to use.

OPERATING LIMITS

  • Max.medium temperature+40°C
  • Max.ambient temperature+40°C
  • PH level from 6.5-8.5
  • Maximum sand content is 01%.Passage of suspended solids up  to 0.2mm.
  • Voltage fluctuation range:0.9-1.1 times of the rated value lmmersion depth from 0.5m-5m

MOTOR INFORMATION

  • 2 pole induction motor
  • Single phase/three phase,220v-240v,380v,400v,415v,460v .50hz,60hz,or 50/60Hz(on demand)
  • Thermal protector for single phase /three phase pumps
  • Insulation class:B/F/H
  • Protection class:IPX8

MATERIAL

  • Pump body:Cast iron/Aluminum/Stainless steel
  • Motor housing: Aluminum
  • Impeller:Aluminum
  • Motor wire:copper
  • Mechanical seal:Graphite&Ceramis
  • Shaft:45#steel/stainless steel
Qdx Electric Submersible Pump with Float Switch (Aluminum Housing)
Qdx Electric Submersible Pump with Float Switch (Aluminum Housing)
Qdx Electric Submersible Pump with Float Switch (Aluminum Housing)
Qdx Electric Submersible Pump with Float Switch (Aluminum Housing)
Qdx Electric Submersible Pump with Float Switch (Aluminum Housing)
We produce also many other types of Submersible pumps accoridng to client request.
If you need Above QDX submersible pumps,welcome to inquiry now.
